Brakes

Hrvatski

---

Generally, all Virago motorcycles on rear wheel do have a drum brake. Smaller Virago models (from xv125 up to xv535) do have only one brake disc on front wheel (right side) while bigger Virago models (from xv700 to xv1100) do have two brake discs on front wheel. (Yamaha xv750 Virago at the beginning of its production (1981-1983) did have only one brake disc on front wheel but in 1984. it was changed to two brake discs).

xv535 1987 one piston caliper solid disc

xv535 1993 one piston caliper slotted disc

xv535 1995 two pistons caliper drilled disc

At the beginning brake discs were of sold profile, later spots (slotted profile) and finally holes (drilled profile) were added on discs for noise reduction and better cooling. Also at the beginning brake calipers did have only one-piston caliper, but later it was changed to two-piston calipers.

old xv535 brake type with one-piston caliper 2GV-25810-00-00

new xv535 brake type with two-piston calipers 3JB-2580U-11-00

Single Caliper Assy Code	xv125	xv250	xv400	xv500	xv535
29L-2580T-00-00	-	-	-	1983	-
22U-25810-00-00	-	-	-	1987	-
3DM-2580U-01-00	-	1989-1994	-	-	-
4HM-2580T-00-00	1997-2000	1994-2004	-	-	-
3BG-2580T-00-00	-	2005-2007	-	-	-
2GV-25810-00-00	-	-	-	-	1987-1988
3JB-2580U-00-00	-	-	1991-1992	1992-1994	1989-1994
3JB-25810-10-00	-	-	1994	1995	1995
3JB-25810-11-00	-	-	-	1996-1998	1996-2001

---

Dual Caliper Assy Code	xv700	xv750	xv920	xv1000	xv1100
4K0-25810-02-00 4K0-25810-11-00	-	-	1981-1982	-	-
4H7-25810-12-00	-	1981-1983(1)	1982-1983(1)	-	-
42H-25810-00-00 42H-25810-10-00	-	1984-1986(2)	-	-	-
42H-25810-01-00 42H-25810-11-00	1984-1987	1988-1995	-	1984-1985	1987-1995
42H-2580U-00-00 42H-2580T-00-00	-	1996-1998	-	1986-1988	1995-1999

⁽¹⁾ = Single disc system (all others are two discs system)
⁽²⁾ = Japanese market
